  Pillow-Type Packing Machine
Features:

This machine is for  packaging  solid  products  with  regular  shape  such  as  biscuit,  bread,  candy,  commodities  and  industrial  parts.

The  bulk  products  need  to  be  placed  in  a  tray  to  form  regular  shape  first  before  being  packaged.

Features:

PLC control  and Touch-Screen HMI  that  ensure  easy  parameters  setting,  high  speed  and  high  efficiency .

Photoelectric tracking technology and digital input that ensure accurate sealing & cutting position.

Self  alarm  display  the  malfunction.

Constant  temperature  control,  intelligent  control  and  being  suitable  for  all  kinds  of  packaging  materials.

Dual  frequency  conversion  control,  bag  length  can  be  set  and  cut  in  one  step  so  as  to  save  time  and  film.

Operator  can  set  the  machine  stopping  position,  so  there  is  no  sticking  to  the  knife  or  film wasted.



Specification:
Model TCZB-250X Pillow Type Packing Machine
Dimension L3920mmW670mmH1320mm
Weight 700kgs
Electrical 220V
Power 2.4kw
Bag length 65-190mm
Bag width 30-110mm
Film Width 250mm
Product Height 40mm
Packing speed 40-230 bags / min
Packing type back pillow sealing
